3-5.5 Inch Drill Rods Api Dth Drilling Pipe For Mining And Water Well

3-5.5 Inch Drill Rods Api Dth Drilling Pipe For Mining And Water Well

    • 3-5.5 Inch Drill Rods Api  Dth Drilling Pipe  For Mining And Water Well
    • 3-5.5 Inch Drill Rods Api  Dth Drilling Pipe  For Mining And Water Well
    • 3-5.5 Inch Drill Rods Api  Dth Drilling Pipe  For Mining And Water Well
    • 3-5.5 Inch Drill Rods Api  Dth Drilling Pipe  For Mining And Water Well
  • 3-5.5 Inch Drill Rods Api  Dth Drilling Pipe  For Mining And Water Well

    Product Details:

    Place of Origin: China
    Brand Name: Sanrock
    Certification: API

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Piece/Pieces
    Price: negotiable
    Packaging Details: Nude package or Tray or Wooden Case
    Supply Ability: 5000 Piece/Pieces per Month
    Contact Now
    Detailed Product Description
    Type: Drill Pipe Machine Type: Drilling Tool
    Material: Carbon Steel Processing Type: Forging
    Use: Ore Mining Diameter: 3-5.5inch
    Application: Water Well Length: 1-12 Meter
    Thread: API Standard Size: 76/89/102/114/127/140
    Color: Black Or Customized
    High Light:

    rock drill rods

    ,

    oil well drill pipe

    3-5.5 Inch Drill Rods Api Dth Drilling Pipe For Mining And Water Well



    Drill pipe, is hollow, thin-walled, steel or aluminium alloy piping that is used on drilling rigs. It is hollow to allow drilling fluid to be pumped down the hole through the bit and back up the annulus. It comes in a variety of sizes, strengths, and wall thicknesses, but is typically 27 to 32 feet in length . Longer lengths, up to 45 feet, exist


    Standard DTH drill pipe:

    Diameter: 76mm, 89mm, 102mm, 114mm, 127mm, 140mm;

    Length: 1000mm, 1500mm, 2000mm, 3000mm, 5000mm, 6000mm;

    Thread: 2 3/8” API REG, 2 7/8” API REG, 3 1/2” API REG, 4 1/2” API REG,

                   2 3/8 API IF, 3 1/2 API IF



    Product Specification

    Rod dia(mm) Rod Length(mm) Thickness (mm) Connect  Thread  Trigger Slot
    inch mm
    3 76 1000-6000 5 API2 3/8”REG 57/64.5
    3 76 1000-9000 8 API2 3/8”REG 57/64.5
    3 1/2 89 1000-6000 6 API2 3/8”REG 70/64
    3 1/2 89 1000-9600 8 API2 3/8”REG 70/64



    Rod dia(mm) Rod Length(mm) Thickness (mm) Connect  Thread  Trigger Slot
    inch mm
    4 102 1000-9000 10 API2 3/7”REG 76/89
    4 1/2 114 1500-7620 6 API3 1/2”REG 89/95
    4 1/2 114 1500-9140 8 API3 1/2”REG 89/95
    4 1/2 114 1500-9140 10 API3 1/2”REG 89/95
    4 1/2 114 1500-9140 18 API3 1/2”REG 89/95



    Rod dia(mm) Rod Length(mm) Thickness (mm) Connect  Thread  Trigger Slot
    inch mm
    5 127 1500-9500 12 API3 1/2”REG 89
    5 127 1500-9500 14 API3 1/2”REG 89
    5 127 1500-9500 18 API3 1/2”REG 89
    5 1/2 140 1500-9500 9 API4 1/2”REG or 4’FH 114
    5 1/2 140 1500-9500 10 API4 1/2”REG or 4’FH 114
    5 1/2 140 1500-9500 12 API4 1/2”REG or 4’FH 114
