Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig

1 Set/Sets
MOQ
negotiable
Price
Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Water Well Drilling Rig
Name: Water Well Equipment
Power Type: Diesel
Engine: Yuchai
Power(w): 95KW
Drilling Depth: 400m
Drilling Diameter: 140-400mm
Lifting Force: 25T
Rotating Torque: 7500-10000N.m
Rotate Speed: 45-115rpm
Drill Rod Length: 1.5m/2.0m/3.0m
Drill Rod Diameter: 89mm/102mm/108mm
Walking Speed: 2.5km/h
Application: Water Well Drilling Rig Mobile Drilling Rig,drilling Well
Feature: Hydraulic Controlling,Light Weight High Drilling Efficiency
Usage: Water Well
After-sales Service Provided: Video Technical Support
Warranty: 1 Year
Type: Rotary Drilling Rig
Weight: 8200 KG
Dimension(l*w*h): 5900* 2100* 2850mm
High Light:

crawler drill machine

,

water drilling rig machine

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: Sanrock
Certification: CE ISO 9001:2015
Model Number: SR395L
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description









































Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig

SR-395L hydraulic water well drilling rig is widely used for water well drilling, geothermal air-conditioning project and other boreholes, especially applicable to mountain area and rock formation water engineering. Much higher efficient than the traditional mud rotary drill rigs, creating the considerable economic benefit for users. Especially solve problems to drill hard rocks that the traditional rotary drilling rig meet and it should work with air compressor.

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 0

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 1

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 2Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 3

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 4

Products Description

Type
Rotary Drilling Rig
Power Type
Diesel
Drilling Diameter
140-400mm
Drilling Depth
400m
Name
Water Drilling Rig Machine
Product name
water well drilling rig
Application
Water Wells Rock Drill Rig
Feature
Hydraulic Controlling,Light Weight ,High Drilling Efficiency
Engine
Yuchai
   Power   95KW
Lifting force
25T
Rotating torque
7500-10000N.m
Walking speed
2.5km/h
Rotate speed
45-115rpm
Drill pipe diameter
89mm,102mm,108mm
Drill pipe length
1.5m,2.0m,3.0m
Dimension(L*W*H)
5900* 2100* 2850mm
Weight:
Weight:8200 KG




Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 5

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 6

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 7Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 8

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 9



Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 10

Company Profile

Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 11



Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 12



Crawler Well Drilling Equipment Borehole 400m Deep Hydraulic Water Well Drilling Rig 13

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.

2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.

3.How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.

4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
