Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig

1 Set/Sets
MOQ
negotiable
Price
Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Rotary Drilling Rig
Engine: Yuchai
Rock Hardness: F=6-20
Power Type: Diesel,Electric,Air Motor
Usage: Ore
Power(w): 70KW
Drilling Depth: 30m
Drilling Diameter: 105-220mm
Product Name: Dth Drilling Rig
Air Consumption: 13-22m3/min
Working Pressure: 1.0-2.4Mpa
Name: DTH Drilling Machine
Application: Mining,quarry,drilling Blast Hole,mining And Construction
Rotational Torque: 5000N.m
Lifting Force: 45KN
Rotate Speed: 0-120r/min
Walking Speed: 2.5km/h
Feature: High Drilling Efficiency
Dimension(L*W*H): 5800*2330*2500mm
Weight: 7200 KG
High Light:

120r/min DTH Drilling Machine

,

70KW Separated Mining Drilling Rig

,

Rotary Blast Hole DTH Drilling Rig

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: Sanrock-JK
Certification: IOS9001 CCC
Model Number: R67
Payment & Shipping Terms
Packaging Details: 40' HQ container for one drilling rig and one air compressor with related drilling tools; Nude package for drilling rig,spare parts in plywood cases.
Delivery Time: 10-20days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 Set/Sets per Month
Product Description

Crawler Hydraulic DTH Drilling Machine Rotary Blast hole Separated Mining Drilling Rig

1.This drill rig upgrades tramming components, hydraulic system, feed beam, rotary head and whole rig chassis to optimize the functional capacity of the drill rig.

2. The upgraded rig with improved features of strong climbing ability, large rotation torque & long life motor is widely applicable to various surface mining environment.

3. With larger displacement single motor, compact size & large rotation torque, the rotary head adjustable according to different work conditions & requirement, greatly increasing drilling efficiency.

4. All controls integrated on the control panel for convenient operation, higher work efficiency & lower drilling cost, safer and more comfortable operation.

5. Piston tramming motor, special process casted track shoe for stronger tramming traction force & more stable quality.

Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 0

Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 1Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 2Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 3Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 4Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 5

 Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 6



Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 7Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 8Crawler Hydraulic DTH Drilling Machine Rotary Blast Hole Separated Mining Drilling Rig 9
