Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment

1 Set/Sets
MOQ
negotiable
Price
Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Water Well Drilling Rig
Name: Water Well Drilling Equipment
Power Type: Diesel
Engine: Yunnei
Power(w): 60KW
Drilling Depth: 180m
Drilling Diameter: 130-254mm
Mud Pump (Recommended): BW160/10
Elevating Capacity: 12 Ton
Rotary Torque: 3200-4600 N.m
Rotary Speed: 45-65rpm
Travelling Speed: 2.5km/h
Climbing Ability Max: 30°
Drill Rod Length: 1.5m, 2.0m, 3.0m
Drill Rod Diameter: 76mm/89mm
Application: Water Well Drilling Rig,agricultural Irrigation Wells
Feature: High Drilling Efficiency,Hydraulic Controlling,Competitive Price
Usage: Water Well
Type: Rotary Drilling Rig
After-sales Service Provided: Video Technical Support
Condition: New
Warranty: 1 Year
Weight: 4500 KG
Dimension(l*w*h): 3800*1500*2200mm
Highlight:

crawler drill machine

,

water well drilling equipment

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: Sanrock
Certification: CE ISO 9001:2015
Model Number: SR180K
Payment & Shipping Terms
Packaging Details: Nude package for machines; Wooden package for spare parts; Or customer demand;
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment

This series of water well drilling machine applicable to drilling water wells, agricultural irrigation wells, geothermal air-conditioning wells and well holes of other purposes, especially applicable to water intake projects in mountain regions and at rock stratums.

Feature
1.This model rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.
2.Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.
3.Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.
4.The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 0

 Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 1Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 2

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 3

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 4Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 5

Products Description

Product name Water Wells Drilling Rig
Name Water Drilling Rig
Power Type Diesel
Climbing Ability max 30°
Drilling Diameter 130-254mm
Drilling Depth 180m
Engine model Yunnei
Power(w) 60KW
Working Pressure 1.7-2.5Mpa
Rotary Torque 3200-4600 N.m
Rotary Speed 45-65rpm
Elevating capacity 12 Ton
Application water well drilling rig,agrecultural irrigation well
Drill rod length 1.5m, 2.0m, 3.0m
Drill rod diameter 76mm/89mm
Travelling speed 2.5km/h
Dimension(L*W*H) 3800*1700*2250mm
Weight 4500 KG




Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 6



Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 7

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 8Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 9Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 10Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 11

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 12

Company Profile

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 13

Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 14



Deep Well Drilling Machine Agricultural Irrigation Bore hole Water Well Drilling Equipment 15

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.

2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.

3.How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.

4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
