Crawler Environmental Sampling Drilling Rig Hydraulic Borehole Geotechnical Drilling Rig

1 Set/Sets
Crawler Environmental Sampling Drilling Rig Hydraulic Borehole Geotechnical Drilling Rig
Features Gallery Product Description Request A Quote
Product Name: Hydraulic Core Drilling Rig
Type: Core Drilling Rig
Name: Environmental Drilling Rig
Feature: High Drilling Efficiency,Wireless Remote Control
Power Type: Diesel
Power(w): 93KW
Drilling Depth: 180m
Drilling Diameter: 150-250mm
Impact Frequency: 2100b/min
Impact Power: 480N.m
Torque Of Impact Power Head: 900N.m
Name: Core Drilling Rig
Application: Coring Machine,Gelogical Prospecting
Usage: Coal,water Well.core Sample
After-sales Service Provided: Video Technical Support
Dimension(l*w*h): 4200*1850*2400mm
High Light:

portable core drilling machine


portable hydraulic water well drilling rig

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: SRM135
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Diesel Power Core Portable Hydraulic Water Well Drilling Rig 130m 180m 200m



Product Specification


Machine Parameter
Drilling depth 30--180m
Drill rod caliber 50   42mm
End hole caliber 75   46mm
Max. open hloe caliber 220mm
Drilling angle 90°~75°
Drill weight (No include power) 610kg
Unity machine dimensions 2.1×0.9×1.3m
spindle speed 130, 300, 480, 730, 830, 1045r/min
Spindle stroke 450mm
Max.single line hoisting capacity 1600kg
Single line lifting speed 1.06, 0.67, 0.32m/s
Wirerope caliber 13mm
Wirerope cubic measure 35m
Hug floodgate caliber 254mm
Hug folldgate belt width 50mm
Distance between drill and hole 230mm
Mud pump
Type Horizontal single urn twin-action
Displacement 170L/min
Maximum pressure 1.5Mpa
Work pressure 0.7Mpa
Diesle engine S1105 18HP
Electric motor Y160M—4 15KW
