Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig

1Set/Sets per Month
MOQ
negotiable
Price
Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Water Well Drilling Rig
Name: Water Well Drill Rig
Power Type: Diesel
Power(w): 60KW
Engine: Yuchai
Drilling Depth: 180m
Drilling Diameter: 140-254mm
Swing Torque: 3200-4600N.m
Working Pressure: 1.7~2.5Mpa
Walking Speed: 2.5km/h
Swing Speed: 45-70rpm
Drill Rod Length: 1.5m, 2.0m, 3.0m
Drill Rod Diameter: 76mm/89mm
Feature: High Drilling Efficiency,Hydraulic Controlling,Competitive Price
Application: Water Well Drilling Rig Mobile Drilling Rig,drilling Well
Usage: Water Well
Dimension(l*w*h): 4000×1630×2250mm
Weight: 5200 KG
Warranty: 1 Year
Type: Rotary Drilling Rig
High Light:

180m Hydraulic Water Well Drilling Rig

,

Borehole Deep Water Drilling Rigs

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: SR180
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig Price

1.SR180 series deep(water) well-drilling rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.

2.Water Well Crawler Drilling Rig is a light, highly-efficient and multifunction drilling device,convenient use, reliability and durability, 3.Each hydraulic tubing is covered with a protective shell to effectively extend the service life of pipeline.

4.Lifting force: composite arm with small size yet long stroke, double cylinder lifting, strong lifting capacity 5.Hydraulic oil pump: It uses parallel gearbox to separate oil pump monomer, supply adequate power and distribute reasonable. The hydraulic system adopts unique design, which is easy to maintain and can lower the maintenance cost.

6.Rotary head device: integrated casting gearbox , dual motor power, large torque, durable, small maintenance costs

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 0

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 1

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 2

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 3



Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 4

Extensively applicable to drilling water wells, agricultural irrigation wells, geothermal air-conditioning wells and well holes of other purposes, especially applicable to water intake projects in mountain regions and at rock stratums.

Products Description

Product Name: water well drilling rig
Drilling Depth:180m
The hole diameter:140-254mm
Equipped capacitor:60KW
Using air pressure:1.7-2.5MPA
Air consumption:17-31m3/min
Swing speed:45-70rpm
Climbing angles:30Max
Walking speed:2.5km/h
Swing torque:3200-4600N.m
The engine brand:Yuchai engine
Equipped with hammer:Medium and high wind pressure series
The penetration efficiency:10-35m/h
Drill pipe diameter:76mm / 89mm
Drill pipe length:1.5m / 2.0m / 3.0m
Dimension:4000×1630×2250mm
The weight:5200KG




Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 5Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 6

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 7Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 8

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 9

Company Profile

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 10

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 11

Deep Water Drilling Rigs Borehole 180m Portable Hydraulic Water Well Drilling Rig 12

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.

2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.

3.How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.

4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
