Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs

1Set/Sets per Month
MOQ
negotiable
Price
Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: DTH Drilling Rig
Name: Top Hammer Drill Rig
Machine Type: Drilling Equipment
Application: Rock Drilling,ore Mining,mine,Drilling Holes
Advantage: High Performance,fast Footage Speed And Good Wearing Resistance
Use: Ore Mining,Rock Drilling
Engine: Cummins
Power Type: Diesel
Power: 179kw
Fuel Tank: 450L
Drilling Depth: 24m
Drilling Diameter: 76-115mm
Total Length Of Propulsion Beam: 7300mm
Compensation Stroke: 1200mm
Drill Pipe Specification: T45/T51
Drill Pipe Length: 3660mm
Walking Speed: 4.2km/h
Dimension(L*W*H): 11200*2600*3500mm
Weight: 15000KG
High Light:

Mining Top Hammer Drill Rig Equipment

,

Rotary Blast Hole DTH Drilling Rigs

,

DTH Top Hammer Drill Rig

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: T87
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300Set/Sets per Month
Product Description

Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs

Open-pit hydraulic drill carriage is designed according to the operating conditions of small and medium-sized quarries and small open-pit mines,and is mainly used for drilling hard and medium-hard(F10 and above)rocks.
It can be used for rock blasting and drilling in the construction of quarries,civil works,road projects, open-pit mines and hydro power plant,etc.
The product has withstood the tests of high temperature of 45°C in Laos, high altitude of in Qinghai Province, China,and extreme low temperature of-30°C in Inner Mongolia,China
The cold-drawing structure steel propulsion beam with double-sided guide rails is adopted,with high strength and good pilot accuracy
More intelligent
The intelligent monitoring system displays real-time operation parameters and maintenance tips.
The self-diagnosis fault system displays code prompt and provides quick solution.
The intelligent common-bottom control system accurately control the drilling angle and depth.
The self-adaptive drilling to rock strata reduced the sticking and the loss of drilling tools.
The Io control system,provides synchronous data transmission on APP and displays real-time construction progress.
Path planning, hole sequence planning, graphic guidance,and fast positioning Safety and environmental protection.
Cab with ROPS&FOPS certification.

Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 0

Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 1Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 2Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 3

Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 4

Feature:
1.This product is equipped with a high-efficiency hydraulic rock drill, with fast drilling rate,low energy consumption,flexible maneuverability and strong grade ability. It can be used for drilling operations in complex terrain,Low operating costs
2.The high-power hydraulic rock drill with reverse drilling function minimizes the probability of sticking.
3.The intelligent identification of rock stratum attributes prevents sticking and idle drilling,extending the service life of drilling tools.
4.The reasonable power matching of rock drill-air compressor-engine further reduces fuel consumption.
5.Constant power control,Self-adaptation of operation status
Good adaptability to working conditions.
6.Dual operation mode,one-click switching between economic and intensive mode,Small and flexible body with compact structure,strong grade ability and good,terrain adaptability.
7.Folding arm structure with large coverage area in single positioning
,Meeting the drilling requirements of vertical,inclined and horizontal blasting holes.
8.High reliability,Core components of international famous brands are selected,and the system design is reasonably matched.

Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 5



Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 6

Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 7

Products Description

Product name:Top Hammer Drilling Rig
Operation parameters
Drilling range
m m
76- 115
Economic hole diameter
m m
76, 89, 102
Drill pipe specification
-
T45/T51
Drill pipe length
m m
3660
Drilling depth
m
24
Hydraulic rock drill
Impact power
kW
21
Slewing torque
N m
883
Slewing speed
r p m
0- 150
Engine
Brand
-
CUM M I NS
Model
-
QSC8.3
Power
kW/r p m
179/2200
Fuel tank
L
450
Air compressor
Working pressure
Bar
10
Displacement
m³/min
10
Drill boom
Type
-
Fo ding a rm
Lifting angle
°
70~- 10
Folding angle
°
65~ 165
Swing angle
°
20~-30
Propulsion
Total length of propulsion beam
m m
7300
Compensation stroke
m m
1200
Forward tilting angle
°
140
Turning angle
°
-20~90
Maximum propulsion rate
m/s
0.8
Maximum propulsion
kN
25
Traveling capability
Maximum traveling speed
k m/h
4.2
Max. traction
kN
100
Gradeability
°
25
Swing angle of crawler frame
°
-7~ 12
Chassis ground clearance
m m
400
Dimension
Weight
kg
15000
L × W × H (Working)
m
9.2 × 2.6 × 8.6
L × W × H (Transportation)
m
11.2 × 2.6 ×3.5


Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 8Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 9Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 10



Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 11Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 12Mining Top Hammer Drill Rig Equipment Rotary Blast Hole Hydraulic DTH Drilling Rigs 13
