Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig

1 Set/Sets
MOQ
negotiable
Price
Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Water Well Drilling Rig, Crawler Water Well Drilling Rig
Name: Water Well Drilling Equipment ,Water Well Drilling Machine
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Application: Water Well Drilling Rig,agricultural Irrigation Wells
Type: Rotary Drilling Rig
Power Type: Diesel
Engine: CUMMINS
Power(w): 92KW
Drilling Depth: 100m/200m/300m/350m
Drilling Diameter: 105-305mm
Lifting Force: 18T
Rotary Torque: 4000-8000N.m
Rotary Speed: 60-120r/min
Air Pressure: 1.2-3.5Mpa
Air Consumption: 16-55 M³/min
Jacks Stroke: 1.45m
Axial Pressure: 3T
Small Auxiliary Winch Lifting Force: 1.5T
Drill Pipe Length: 6m
Drill Pipe Diameter: 89mm
Fast Lifting Speed: 30m/min
Fast Feeding Speed: 60m/min
Walking Speed: 2.5km/h
After-sales Service Provided: Video Technical Support
Usage: Water Well
Dimension(l*w*h): 6000*1700*2200mm
Weight: 7500KG
High Light:

Borehole Well Drilling Rig

,

350m Well Drilling Rig

,

350m Depth Water Drilling Machine Borehole
Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: SR350S
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description
Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 0
Top-drive type, high-efficiency, multi-functional fully hydraulic drilling rig features advanced technology, easy use, high operating efficiency, reliability and durability. This drilling rig is widely used in drilling water wells, detection wells, dewatering wells, rescue wells, ground source air conditioning holes, coal bed methane, natural gas, oil exploration and other projects.
1.The drilling rig can use with air compressor for DTH drilling in various formations in high-temperature areas, alpine areas and plateau areas, in the range of Plattes hardness f=4-20 drilling holes in the rock has a high drilling speed.
2.Equipped with hydraulic outriggers for leveling the rig and keeping the machine stable. The main engine is equipped with a high-power diesel engine with strong power to meet work needs.
3.Equipped with hydraulic lifting and lowering composite drill boom, which saves space and provides powerful lifting force for deep hole operations.
4.Centralized operating handles, reasonable layout, safe and feasible. Excellent workmanship, durable, and low maintenance costs.

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 1Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 2


Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 3

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 4Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 5


Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig

Products Description

Model
Unit
SR350S
Max drilling depth
M
350
Drilling diameter
mm
105-305
Engine brand
/
Cummins
Power
kw
92
Rotary motor brand
/
Eaton
Pump brand
/
Permco
Air pressure
Mpa
1.2-3.5
Air consumption
m³/min
16-55
Drill pipe length
m
6
Drill pipe diameter
mm
89
Axial pressure
T
3
Lifting force
T
18
Fast lifting speed
m/min
30
Fast feeding speed
m/min
60
Max rotary torque
Nm
8000/4000
Max rotary speed
r/min
60/120
Big auxiliary winch lifting force
T
/
Small auxiliary winch lifting force
T
1.5
Jacks stroke
m
1.45
Drilling efficiency
m/h
10-35
Moving speed
Km/h
2.5
Uphill angle
/
21°
Weight
T
7.5
Dimension
mm
6000*1700*2200
Working condition
/
Unconsolidated formation and stone head
Drilling method
/
Top drive hydraul ic rotary and pushing, hammer or mud drilling

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 6Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 7

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 8Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 9

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 10



Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 11Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 12

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 13

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 14



Company Profile

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 15

Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 16



Water Drilling Machine Borehole 350m Depth Hydraulic Crawler Water Well Drilling Rig 17

1.What can you buy from us?
DTH drilling rig,core drilling rig,reverse circulation drilling rig ,highway pile driver,solar pile driver ,
anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,DTH hammer,drill rod,
screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,
piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.


2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.

3.How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping.
Shipping efficiency depends on country and city you want to ship to.
For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.

4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
