Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor

1 Set/Sets
MOQ
negotiable
Price
Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Screw Air Compressor,Air Compressor Machine
Name: Diesel Screw Air Compressor
Power: 410KW
Power Source: Diesel
Air Consumption: 31-29m²/min 36.5-32m²/min
Speed: 1600/1400rpm 1830/1400rpm
Fuel Tank Capacity: 700L
Lubricating Oil Capacity: 120L
Cooling Method: Both Air/Water Cooling Available
Application: Mining Project,Coal,Ore
Type: Screw
Core Components: PLC, Pressure Vessel, Engine, Motor, Pump, Bearing
Configuration: Stationary
Dimension(l*w*h): 4100*1800*2050mm
Weight: 5600KG
Highlight:

Stationary Screw Air Compressor 50HP

,

Water Well Air Compressor Machine 50HP

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: Customized
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 18-25 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 0Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 1

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 2Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 3

1. The screw air compressor is designed for high efficiency and performance. It utilizes screw technology to deliver a high volume of compressed air with minimal energy consumption. 2. It can handle heavy-duty tasks and provide a continuous supply of compressed air, allowing for seamless operation in demanding environments. 3. The is equipped with an advanced control system that offers precise control over the compressor's operation. The control system enables accurate monitoring of pressure levels, temperature, and other parameters, ensuring performance and safety. 4. The is designed for easy maintenance and serviceability. It features accessible maintenance points and user-friendly components, simplifying routine inspections, oil changes, and filter replacements.

High-Pressure Performance: making it suitable for demanding applications such as water well drilling and construction works. Reliable and Quiet Operation: This diesel-powered air compressor is designed to be quiet and lubricated, ensuring a smooth and efficient operation, as requested by environmentally conscious customers. Versatile and Portable: With its portable configuration, the screw air compressor can be easily moved and set up on-site, making it ideal for projects in various locations.
Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 4Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 5Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 6

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 7

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 8Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 9



Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 10

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 11

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 12

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 11
Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 14

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 15

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 16Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 17

Company Profile

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 18

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 19

Stationary Screw Air Compressor Water Well Air Compressor Machine 50HP Screw Air Compressor 20

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
