410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min

1 Set/Sets
MOQ
negotiable
Price
410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Screw Air Compressor,Air Compressor Machine
Name: Diesel Screw Air Compressor
Power: 410KW
Power Source: Diesel
Pressure: 21-25bar/21-34bar
Air Consumption: 31-29m²/min 36.5-32m²/min
Speed: 1600/1400rpm 1830/1400rpm
Fuel Tank Capacity: 700L
Lubricating Oil Capacity: 120L
Cooling Method: Both Air/Water Cooling Available
Application: Mining Project,Coal,Ore
Type: Screw
Core Components: PLC, Pressure Vessel, Engine, Motor, Pump, Bearing
Configuration: Stationary
Dimension(l*w*h): 4100*1800*2050mm
Weight: 5600KG
Highlight:

Diesel Rotary Screw Air Compressor

,

410KW Rotary Screw Air Compressor

,

29m2/min Rotary Screw Air Compressor
Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: Customized
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 18-25 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

screw air compressor used with water well drilling rig
This specialized rotary screw air compressor is engineered to deliver high-efficiency compressed air supply for water well drilling operations.
Featuring robust twin-screw technology, to power down-the-hole hammers and rotary drilling systems. superior cooling and lubrication for extended duty cycles in harsh drilling environments.
Integrated with vibration-resistant components and heavy-duty filtration systems, this compressor maintains high performance under dust and high-temperature conditions.
Automatic load/unload controls and energy-saving VFD options enhance fuel efficiency for mobile drilling rig configurations. With protection rating and corrosion-resistant coatings, it meets rigorous drilling industry standards for reliability in borewell construction and geothermal drilling applications.

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 0410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 1



410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 2



410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 3

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 4410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 5

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 6410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 7

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 8

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 9


410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 10

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 11

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 12410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 13

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 14410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 15
