Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine

1Set/Sets per Month
MOQ
negotiable
Price
Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Hydraulic Core Drilling Rig
Name: Borehole Drilling Rig,core Drilling Rig
Type: Core Drilling Rig
Usage: Water Well.core Sample
Feature: High Drilling Efficiency,portable，Light Weight
Application: Geological Exploration
Power: 16.2KW
Rated Speed: 2200r/min
Drilling Diameter: 75-325mm
Drilling Depth: 200m
Drill Rod Diameter: 42-60mm
Dimension(l*w*h): 2700*900*1500mm
After-sales Service Provided: Online Support
Maximum Lifting Weight Of Vertical Shaft: 25KN
Maximum Feed Pressure Of Vertical Shaft:: 15KN
Maximum Output Torque Of Vertical Shaft: 15KN
Vertical Shaft Speed(4th Gear): 71,142,310,620 R/min
Vertical Shaft Travel: 450mm
Hole Dip Angle: 90-75°
Final Hole Diameter: 75mm
Single Package Size: 2150×880×1560 Mm
Single Gross Weight: 760 Kg
Highlight:

hydraulic core drilling rig machine

,

rotary borehole drilling equipment

,

geological core drilling rig
Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: SRC200
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 0

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 1

Hydraulic Exploration Geological Core Drilling Rig – 200m Depth
This hydraulic-powered exploration core drilling rig is specifically engineered for geological survey, mineral prospecting, and geotechnical investigation, with a maximum drilling depth of 200 meters. The fully hydraulic drive system delivers smooth and precise control over rotation speed, feed pressure, and rod handling, ensuring efficient coring in diverse formations including rock, soil, and weathered strata.
Key features include:
High-torque hydraulic rotary head for reliable diamond core drilling (NQ, HQ, BQ).
Hydraulic feed and retraction for accurate bit pressure control and reduced rod wear
Compact and modular design for easy transport and setup in remote or confined sites.
Durable construction suited for continuous operation in tough field conditions.

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 2

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 3

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 4

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 5

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 6

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 7

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 8

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 9

Products Description

Brand Name:SANROCK
Product name :Core Drilling Rig

Name: Core Drilling Machine
Power Type :Diesel

Feature :High Drilling Efficiency,portable,Light Weight
Packaging Details:packing according to customer's requirement.

Model number:Diesel engine
Rated speed:2200r/min
Power:16.2KW
Borehole depth:200M
Pipe diameter:50mm
Opening diameter:75-325mm
Final hole diameter:75mm
Hole dip Angle:90-75°
Gyrator
Vertical shaft speed(4th gear):71,142,310,620 r/min
Vertical shaft travel:450mm
Maximum output torque of vertical shaft:15KN
Maximum feed pressure of vertical shaft:15KN
Maximum lifting weight of vertical shaft:25KN
Single package size:2150×880×1560 mm
Single gross weight:760 kg

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 10

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 11

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 12

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 13

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 14

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 15

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 16

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 17






Company Profile

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 18

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 19

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 20


Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 21

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 22
