High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

1Set/Sets per Month
MOQ
negotiable
Price
High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Pneumatic Rock Drill
Type: Rotary Drilling Rig
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Application: Quarry, Mining, Road Construction,concrete Breaking
Drilling Diameter: 50-57mm
Drilling Depth: 6m
Impact Frequency: ≥33 Hz
Air Consumption: ≤33 L/S
Air Pressur: 0.4-0.63 Mpa
Cylinder Diameter: 65mm
Weight: 20.5 KG
Key Selling Points: Easy To Operate
Highlight:

High Impact Air Pick Hammer

,

Concrete Demolition Rock Drilling Machine

,

Hydraulic Jack Hammer Road Breaker

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: Y20
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15days
Payment Terms: L/C,D/A,D/P,T/T
Supply Ability: 5000Set/Sets per Month
Product Description

Our Y20 handheld pneumatic rock drill is a lightweight industrial perforator weighing 20.5 kg. It delivers ≥26 J impact energy for blasting‑hole drilling on medium‑hard and hard rock. With compact 561‑mm body length and anti‑slip dual handles, this air‑powered jackhammer adapts to downward, horizontal and inclined borehole work. Widely deployed in mine excavation, quarrying, roadworks, water‑conservancy and stone‑blasting projects, it features low air consumption, easy maintenance and dependable performance for long‑time harsh‑site operation

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine


High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine



High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine


High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

Products Description

Brand Name:Sanrock
Product name: Rock Drilling Machine
Model:YO20
Drilling Diameter:34-42mm
Drilling Depth:5m
Rock Hardness:F=6-20
Piston Stroke:52mm
Cylinder Diameter:64mm
Working Pressure:0.4-0.63 Mpa
Impact frequency:≥33Hz
Impact energy:≥26J
Air Consumption:1.7m3/min
Drill Pipe Size:B22*108mm
Weight:21kg
Package Size:590*280*180mm
air leg:FT100


High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine


High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

Company Information

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine


High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

High Impact Performance Air Pick Hammer Concrete Demolition and Road Breaking Hand Rock Drilling Machine

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.


2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.


3.How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
