Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

1Set/Sets per Month
MOQ
negotiable
Price
Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Pneumatic Rock Drill
Type: Rotary Drilling Rig
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Application: Quarry, Mining, Road Construction,concrete Breaking
Drilling Diameter: 50-57mm
Drilling Depth: 6m
Impact Frequency: ≥33 Hz
Air Consumption: ≤33 L/S
Air Pressur: 0.4-0.63 Mpa
Cylinder Diameter: 65mm
Cylinder Diameter: 65mm
Weight: 20.5 KG
Key Selling Points: Easy To Operate
Highlight:

Portable Rock Jack Hammer

,

Horizontal Borehole Rock Drilling Machine

,

Inclined Borehole Hydraulic Jack Hammer

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: Y20
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15days
Payment Terms: L/C,D/A,D/P,T/T
Supply Ability: 5000Set/Sets per Month
Product Description

When you require flexible on‑site hole‑drilling equipment for outdoor engineering, pick the Y20 handheld rock drill. This air‑driven handheld machine specializes in downward and tilted blast boreholes on hard rock strata. No complicated installation is required; workers can adjust drilling angles freely at quarries, coal mines, highway building sites, irrigation works and defence stone‑engineering zones. Compatible with standard H22×108 drill shanks, the Y20 accepts assorted drill bits for diverse rock conditions. Light‑duty frame design enables convenient transport between scattered construction spots for field‑based blasting preparation work.

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale


Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Products Description

Brand Name:Sanrock
Product name: Rock Drilling Machine
Model:YO20
Drilling Diameter:34-42mm
Drilling Depth:5m
Rock Hardness:F=6-20
Piston Stroke:52mm
Cylinder Diameter:64mm
Working Pressure:0.4-0.63 Mpa
Impact frequency:≥33Hz
Impact energy:≥26J
Air Consumption:1.7m3/min
Drill Pipe Size:B22*108mm
Weight:21kg
Package Size:590*280*180mm
air leg:FT100

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale




Company Information

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale


Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

Portable Rock Jack Hammer Horizontal and Inclined Borehole Work Rock Drilling Machine for sale

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.


2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.


3.How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
